Heavy Duty Tripod Turnstile
ZOJE-S906 Heavy Duty Tripod Turnstile has a longer and larger cabinet size, which is easy to integrate multiple types of systems at the same time and supports outdoor all-weather use. The top of the cabinet is equipped with a bevel protrusion, which can be integrated with an LCD screen to display ticket information or advertisements. It is widely used in scenic spots, gyms and other consumer places.
Send Inquiry
Product Description
Heavy duty tripod turnstile ZOJE-S906
ZOJE-S906 heavy duty tripod turnstile is an attractive tripod turnstile. It is reliable and efficient for the automation of secure entrance control.
The cabinet will offer enough space for all mechanical and electronic components integrating with a wide range of access control system, such as coin collector, paper ticket collector, IC / ID / RFID / HID card reader, QR code scanner, fingerprint, face recognition and other biometric modules.
This can be indoors or outdoors and withstand severe environment. Can effectively prevent trailing, popular used for Widely used in ticketing places such as tourist attractions.
ZOJE Tripod turnstiles are compact and cost-effective entrance solutions.The body is made of brushed stainless steel 304 or 316 which is robust, rigid, anti-rust and durable.
In case of emergency, the turnstile arm will drop down to allow free passage when power off.
We are also professional customize as your idea or project. Contract with our sales get a professional and suitable solution for you
Product Parameter (Specification)
| Standard | Optional | |
| Turnstile Type | Heavy duty Tripod Turnstile | - |
| Dimension | L1400mm*W280mm*H1000mm | Customized |
| Material | 304 Stainless Steel | 316 Stainless Steel |
| Material Thickness | 1.5mm | 1.2mm/1.5mm/2.0mm |
| Channel Width | ≤500mm | Customized |
| Drive Type | Semi-Automatic(Solenoid) | Automatic(Brush/Brushless/Servo motor） |
| Direction | Single / Bidirectional | - |
| Power Supply | AC110-230,50/60Hz | - |
| Unlock time | 0.2S | |
| Function | Fail safe | |
| Operation Voltage | DC24V,3A | - |
| Working environment | Indoor & outdoor | - |
| Working Temperature | -70 C -15 C | - |
| Relative Humidity | Less Than 95%, No Condensation | - |
| Pass Speed | 35/Minute | - |
| Input Interface | Dry contact/Relay Signal | - |
| Communication Interface | RS485/TCPIP | - |
| LED Indicator | Yes | - |
| Emergency | Arm Drop Automatic | - |
| Access Control | Can be integrated with any kind of access control system. |
Product Feature And Application
ZOJE Heavy Duty Tripod Turnstile Feature and application
● Unique technology: HDY hydraulic buffer device. Makes the system run more smoothly, silently, and has a longer service life.
● Equipment With Power Off The Rod, Electric Automatic Rod Function
● The Equipment Has A Device And Circuit Testing Function, Easy Maintenance
● Equipment With Traffic Indicator
● Equipment With Automatic Protection, Automatic Reset
● Unified standard external electrical interface, which can be connected with various reading and writing devices(ID Card / IC Card /EMcard / Fingerprint Face Recognition / QR Code / ESD system)
● ZOJE Tripod Turnstiles widely used in Construction Sites (Employee Access Management System), Scenic Spots (Ticketing System), Gym (Ticketing System) and other places, and can be easily integrated with your existing control software.
Product Details
